Temperature detection range 35℃~42℃, accuracy ±0.2℃
support 50,000 face database
100 milliseconds fast recognition
8 inch HD LCD display
Local voice alarm after abnormal temperature
Support Wigan protocol, direct access control and control of various gates
Rich hardware interface, integrated 100 megabit Ethernet port, audio interface, Wigan interface, relay interface, TF card, USB and other interfaces
Using 1/2.8" 2 million pixels line by line scan image sensor, low illumination excellent
Maximum output resolution 1920×1080@30 fps, Fine picture
support 2 D、3D digital noise reduction function, clean screen, low noise
Support H.265/H.265/H.264/MJPEG video compression algorithm, support multi-level video quality configuration, coding complexity settings low power consumption, motherboard power consumption as low as 5 watts
Linux software architecture stable and reliable, easy to expand
Support secondary development of device-side application software
Support various software and hardware customization
Display :8 inches LCD
Thermal image sensor: thermal image infrared temperature sensor
Temperature range :35~42℃, accuracy :±0.3℃
Detection distance :0.4 m ~0.7 m
Lens focal length 1.8 mm, field of view angle 118°
lowest illumination :0.005 Lux@F1.2 color mode
Dynamic range :≥120 dB
SNR :≥46 dB (AGCOFF)
Exposure mode: Program mode (customizable shutter interval), shutter mode (1/5-1/20,000 s), slow shutter support
White balance: automatic, indoor, outdoor, sodium lamp mode, manual
Digital noise reduction: DNR,3DNR support
Day and night mode: Fixed color
Maximum resolution :1920 x1080@30fps
Resolution :1920 x1080、1280x960、1280x720、720x576、640x480、352x288、320x240、176x144
Photo MJPEG：1920x1080、1280x720
Number of face base: up to 50,000
Speed of identification :≤300 ms
Live detection: support
Mask testing: Support
Abnormal Temperature Alarm: Support (Voice)
Power interface: DC12V
Network interface :1 channel 10/100 BaseT Ethernet RJ45 interface
Wigan :1 Rouvigan Interface Output
Switch interface :1 relay output
SD card interface :128 G maximum support
MIC： built
Audio Interface: Built-in 2-way audio output
Working temperature :-10℃~50℃
Humidity :0-90% RH( no condensation)
Power consumption :3.5 W
Dimensions :215*125*20 mm
Weight: 0.63 kg
