1. main parameter
1. Measurement range: human mode: 32.0℃ ~42.9℃
2. Resolution: 0.1℃
3, Accuracy: 32.0℃ -42.9℃ error ± 0.2℃
4, display screen: 5.7-inch color LCD screen
5. Temperature measurement record: the number of detectors and the number of temperature alarm times can be recorded
6. Measure the speed of 1S
7. Personnel pass record: 99999 (five-digit statistics)
8. Alarm record: 99999 (five-digit statistics)
9, historical record query: you can consult the historical records at any time
10: Equipped with restored factory Settings, system registration, password protection, connect the power supply system automatically boot
2. Introduction of the security check function:
★ Detection metal accuracy range: nickel.
★ System detection: start-up automatically for system detection.
★ Function menu display: LCD display function (Chinese / English)
★ System working mode: IR
★ Environmental interference monitoring: the LCD panel displays the current environmental interference in real time, so as to re-select the working frequency or re-select the installation environment
★ Detection area: 6 detection location zones (12 independent probes)
★ Detection and alarm mode: multi-location simultaneous detection and accurate alarm
★ Alarm indication: high brightness display multiple location alarm indication overall sensitivity level: 0-255, sensitivity level of each area: 0-255
★ Area sensitivity calibration indication (the only international patent technology): when it is necessary to calibrate the sensitivity of a detection area separately, the system will automatically and accurately display the position of the current calibration detection area, which can quickly let the user immediately know whether the current need to calibrate the detection area, so as to facilitate the sensitivity adjustment
★ Working frequency bands: 50 selected working frequency bands
★ Time setting of the alarm: 1~9S
★ Alarm volume level: 0~20 level volume
★ Personnel pass record: 99999 (five-digit statistics)
★ Alarm record: 99999 (five-digit statistics)
★ History record query: you can access the history record at any time
★ With restored factory Settings, system registration, password protection, and connect the power supply system automatic boot
★ External device function: can be optional
★ External size: 2230mm (height) X820mm (width) X500mm (deep)
★ Channel size: 1990mm (height) X700mm (W) X500mm (deep)
